Chevrolet Cobalt Service & Repair Manual: Fuel Filler Door
Removal
| 1. |
Remove fuel filler pocket. |
| 2. |
Apply tape around fuel filler area
to protect paint. |
| 3. |
Use a drill to remove rivets (1),
Fig. 1, from fuel filler door. |
| 4. |
Remove fuel filler door (2). |
|
Installation
| 1. |
Position fuel filler door to body and
align mounting holes, Fig. 1. |
| 2. |
Install rivets (1) using appropriate
rivet gun. |
| 3. |
Install fuel filler pocket. |
| 4. |
Remove protective tape from body. |
|
Fig. 1 Fuel filler door
